Invicta Basil Fork Mounted Eco / Heavy Duty Sweeper (IFMS)
| SKU | Product | 1+ Prices include VAT Prices exclude VAT | Quantity | |
|---|---|---|---|---|
| IFMS-1200-ECO | Invicta Basil Fork Mounted Eco / Heavy duty Sweeper: Options: 1200mm Wide 5 Row Sweeper | £558.00 £465.00 | ||
| IFMS-1500-ECO | Invicta Basil Fork Mounted Eco / Heavy duty Sweeper: Options: 1500mm Wide 5 Row Sweeper | £685.50 £571.25 | ||
| IFMS-1800-ECO | Invicta Basil Fork Mounted Eco / Heavy duty Sweeper: Options: 1800mm Wide 5 Row Sweeper | £796.50 £663.75 | ||
| IFMS-1500 | Invicta Basil Fork Mounted Eco / Heavy duty Sweeper: Options: 1500mm Wide 8 Row Sweeper | £895.50 £746.25 | ||
| IFMS-1800 | Invicta Basil Fork Mounted Eco / Heavy duty Sweeper: Options: 1800mm Wide 8 Row Sweeper | £1,072.50 £893.75 | ||
| IFMS-2450 | Invicta Basil Fork Mounted Eco / Heavy duty Sweeper: Options: 2450mm Wide 8 Row Sweeper | £1,243.50 £1,036.25 |
Lighter Duty Tasks | The ECO Range
The 5-row sweeper is ideal for tasks with minimal volume and weight. The Fork Mounted Sweeper is a quick and easy solution for re-heaping loose granule products such as sand, topsoil, grain or similar. Available in 4 width combinations and two brush row combinations.
Heavy Duty Tasks | The Standard Range
The 8-row sweeper is best suited where there are large open spaces and/or heavier masses to sweep. The Fork Mounted Sweeper is a quick and easy solution for re-heaping loose granule products such as sand, topsoil, grain or similar. Available in 4 width combinations and two brush row combinations.
Standard Features
• Interchangeable blue nylon brushes• Facility to hang Fork Mounted Magnet from the frame
• Maximum fork section 150 x 60 mm at 683 mm centres
• Zinc-plated twist screws for safe attachment to truck
• Painted bright orange for safety
Operation
• Position the forks to the correct distance apart to locate into fork hoops
• Drive forks into fork hoops until the tip of the forks touches the stop plate, ensuring twist screws are retracted
• Once fully inserted, tighten the twist screws onto the fork blade until secure
• The attachment is now ready for use
• Lower the brush so bristles contact the surface and drive at a steady pace in a straight line
• Once a pass is complete, lift the brush and reverse to cover the same line again (optional depending on debris and surface)
• Repeat steps 5 and 6 until the area is cleared
• Approach debris piles at right angles to form a single heap, ready for collection
Operate Left/Right Hand Sweep (Optional Setup)
• Insert the sweep angle into the slot on the chosen side of the stop plate
• Insert the safety clip through the hole on the vertical pin over the sweep plate
• Drive forks into fork hoops until the tip of one fork touches the stop plate and the other contacts the sweep angle, ensuring twist screws are retracted
• Manual adjustment may be needed for alignment
• Tighten the twist screws to secure
• The attachment is now ready for use
Maintenance
• Inspect monthly for:A. All weld points
B. Wear and distortion of fork hoops and twist screws
C. Damaged or worn components
D. Condition of bristles
• Report and repair damage before re-use
• Treat surface rust with inhibitors, primers, and paint
• Swap front and rear bristles regularly to ensure even wear
Health & Safety
• Department managers must ensure operators are fully trained in the attachment's operation and maintenance, and that twist screws are fully tightened
• Avoid cornering during sweeping to prevent spillage
• Do not insert forks without retracting twist screws
• Do not reverse with bristles in contact with the surface, as the unit may become dislodged
• When in storage, avoid placing items on the brush hood to prevent damage or injury
Eco Range Models (5-Row):
IFMS-1200-ECO – Brush Width: 1200mm – Rows: 5 – Weight: 27kg – Brush Height: 125mm
IFMS-1500-ECO – Brush Width: 1500mm – Rows: 5 – Weight: 37kg – Brush Height: 125mm
IFMS-1800-ECO – Brush Width: 1800mm – Rows: 5 – Weight: 40kg – Brush Height: 125mm
Heavy Duty Range Models (8-Row):
IFMS-1500 – Brush Width: 1500mm – Rows: 8 – Weight: 51kg – Centre of Gravity: 185mm
IFMS-1800 – Brush Width: 1800mm – Rows: 8 – Weight: 61kg – Centre of Gravity: 185mm
IFMS-2450 – Brush Width: 2450mm – Rows: 8 – Weight: 95kg – Centre of Gravity: 185mm
