Conductive Rubber Bench Matting ESD Bench Matting (CDR0)
Conductive Rubber Bench Matting ESD Bench Matting
The Conductive Rubber Bench Matting ESD Bench Matting
is a two layer anti-static rubber matting solution designed for use on electrical workbenches. Manufactured from rubber, this dual layer mat features a coloured top surface and black bottom surface, providing reliable static control and durability in professional environments.
The top surface incorporates a 0.5 mm thick static-dissipative layer, making it suitable for electrical component manufacturing and refurbishment applications. The smooth surface is solder iron resistant and low reflecting, supporting detailed work while protecting sensitive components from electrostatic discharge.
Grounded via a 10 mm male stud fitted to the mat, Conductive Rubber Bench Matting ESD Bench Matting conforms to IEC 61340-5-1. It provides a point to point resistance (Rp-p) of 5.2 x 10⁷ Ω and a resistance to a groundable point (Rgp) of 2.7 x 10⁷ Ω, delivering dependable anti-static performance.
With a product height of 2 mm, the mat operates within a temperature range of -30°C to +70°C and is suitable for dry indoor environments. It has a tensile strength of 4 MPa, elongation of 250%, and a hardness rating of 70 Shore A, ensuring durability in everyday use.
Available in the following sizes and colours:
- 0.6 m x 1.2 m x 2 mm – Green (Weight: 2.35 kg)
- 0.6 m x 1.2 m x 2 mm – Grey (Weight: 2.35 kg)
Conductive Rubber Bench Matting ESD Bench Matting provides a practical and compliant solution for workstations requiring effective electrostatic protection and long-term durability.
